Using Underfloor Heating with Different Floor Finishes

Underfloor heating can virtually be used under any floor finish. The best floor type for underfloor heating is flooring with a good thermal conductivity to enhance the floor to heat up quicker, give more heat output and run more efficiently. The only difference between which floor finish to use with an underfloor heating system is the thermal conductivity of the material.

Tile & Stone

The best type of flooring to use with underfloor heating is tile and stone. Tile and stone have high thermal conductivity, meaning that the heat from an underfloor heating pipe or wire transfers to the floor surface quickly. Tile and stone also retain heat well making the system efficient. Due to the excellent thermal properties, tile and stone are ideal for use with underfloor heating in high heat loss areas such as conservatories. They can be heated to up to 29°C or more, giving a high heat output of up to 200W/m².

Learn More

Wood & Laminate

Different types of wood flooring have different thermal properties, as such there are differences in their suitability for use with an underfloor heating system. The denser and the thinner the floor boards are, the better they conduct heat and typically more suitable they are for use with underfloor heating.

Engineered timber is the best type of wood flooring to use with an underfloor heating system as it performs well with changes in floor temperature. Other wood flooring may also be used, but with softer and less dense wood attention must be paid to the thickness of floorboards so that the floorboards do not act as an insulator blocking the heat. As a general rule for wood flooring, the floor surface temperature must not exceed 27°C.

Learn More

Vinyl

Vinyl flooring can be safely used with underfloor heating. Vinyl heats up and cools down quickly. Vinyl floors are subject to a top floor temperature restriction, usually 27°C, limiting the heat output so they are not recommended in high heat loss areas such as older conservatories.

Learn More

Carpet

Carpet is suitable for use with underfloor heating, provided that the material of the carpet or underlay does not act as an insulator blocking the heat. The total tog of all materials, including any under and overlays, must not exceed 2.5 tog in order for the system to provide sufficient heat output.

Learn More

Watch our Installation videos under various floor types

icon-checkmark  Under Wood
icon-checkmark  Under Tile
icon-checkmark  Under Carpet

What floor heating product should I use?

A simple guide to make a decision
Under Tile or Stone
> Use Loose Wire at 2” spacing with Self-Leveler.

> Use Heating Mat (or Loose Wire at 3” spacing), with insulation boards.

> Use Heating Mat (or Loose Wire at 3” spacing).
Under Solid Hardwood or Bamboo
Under Sheet Vinyl or LVTs
> Use Heating Mat (or Loose Wire at 2” spacing), with self-leveler

> Use Heating Mat (or Loose Wire at 2” spacing), with insulation boards.

> Use Heating Mat (or Loose Wire at 3” spacing), with self-leveler.
Under Laminate or Floating Wood
Under Carpet
  • Use FOIL between the pad and the carpet
