VLo Econna-12 Joisted Floor System

Diffusion Layer for Even Heat Spread

The VLo Econna-12 Joisted Floor System allows quick installation times due to its dry, screedless installation method and one-piece panel design. The slimline 22mm thick panels with a built-in layer of diffusion foil facilitate an even heat distribution, ensuring no hot or cold spots.

The Econna-12’s low-profile design uses a 12mm heating pipe which is built into the structural floor, making sure there will be no overheating of the floor finish. Its 22mm chipboard panels can be installed over battens or joists with spacings of up to 600mm centres and feature a fluted exit to ensure an easy transition into the neighbouring panel. With no screeding required, the universal panels hold the heating pipe in the optimal position; simply glue and screw down the boards, place the pipes within the grooves and then apply a 6mm ply on top prior to fitting the floor finish.
