S3 Manifold


The Warmup S3 Manifold™ provides flexible zoning and water regulation for 2 to 12 water underfloor heating circuits. It is equipped with all the features needed to commission an underfloor heating system with speed and accuracy.

Key Benefits

icon

Expertly Engineered

Made from 304-grade, laser-etched Stainless Steel for high corrosion resistance

icon

Suitable for up to 12 Heat Zones

Can be used with all Warmup water UFH systems

icon

Quick to Install

Single piece construction with no welds that might corrode and leak over time

S3-Manifold

The Heart of Your Warmup Water Underfloor Heating System

The S3 Manifold ensures operational precision and utilises top of the range components for long-lasting, best-in-class performance. It is constructed from a single piece of 304-grade, laser-etched Stainless Steel for high corrosion resistance with no welds that might corrode and leak over time and provides control for up to 12 heat zones.

The Manifold’s Taconova flow meters improve accuracy and reliability for faster commissioning with lock rings to prevent tampering with the commissioned settings and memory rings that enable the valves to be closed and re-set quickly and confidently during commissioning or maintenance.

The Thermomanometer (combined Pressure and Temperature Gauge) on the flow arm facilitates pressure testing of multiple manifolds simultaneously and allows even easier operational checks. And the Manifold’s standard 3/4″ Eurocones make it compatible with a wider range of heating pipes and fittings. Warmup’s S3 Mixing Unit, Actuator, Isolation Valves and In-Wall Manifold Cabinet are available separately.

In-wall-manifold-cabinet

The In-Wall Manifold Cabinet - Secure Housing for Warmup’s S3 Manifold

The In-Wall Manifold Cabinet provides a secure installation for the S3 Manifold. It is available in multiple widths for use with different manifold sizes: 600mm for 2-3 Port Manifolds, 750mm for 4-6 Port Manifolds, 900mm for 7-9 Port Manifolds and 1050mm for 10-12 Port Manifolds.

It also offers an adjustable internal depth and height for a truly bespoke installation. And with a high-quality finish, the In-Wall Manifold Cabinet features a powder coated door and front panel with a galvanized sheet body for high corrosion resistance.

Warranty

Warranty

10 Years Limited Warranty

The Warmup S3 Manifold is engineered for easy installation, commissioning and years of trouble-free service. Each manifold arm is forged from a single piece of seamless stainless steel and equipped with high quality components for a market leading specification that is backed up by the Warmup 10 year warranty.
